Chipping hammer Rockair GV5D

Out of stock
SKU
731530
£596.25

Shank size Hexagonal 17,3 / R15x60

Product Name Art. nr. Weight Delivery Time Price Qty
Chipping hammer Rockair GV5D

Shank size Hexagonal 17,3 / R15x60

731530 5.20 On request On request

Chipping hammer Rockair GV5D is one of our best-sellers. Available either with a spring or screw retainer, you can also opt for the antivibratile version (GAV5).
GV5 and GAV5 weighs 5.1 kg and 5.6 kg, respectively. Its piston diameter is 28 mm with a bore of 61 mm. The vibration level is 7 m/s² for the GV5 and only 6,6 m/s² for the GAV5. Si le GV5 a un niveau de vibration de 7 m/s², le GAV5 lui descend à 6,6 m/s². Its length is 410 mm, it hits 2550 blows/min for an air consumption of 9,55 l/s.

With the spring retainer, GV5 is only available with the H19x50 shank. If you choose the screw retainer, three shanks are available: h19x50, con.23/16x70 and H/d17,3x60.
GV5 is available in a set including a moil point, a chisel, a wide chisel and a slotting tool.

Applications:
- Facade renovation.
- Small demolition.
- Quick tool changing.
- Vibration reduced version (GAV 5).

Technical details
Weight 5.200000
Manufacturer Favre SARL
Country of Manufacturer France
Weight 5,2
Shank size Hex. (mm) 6kt. 17,3:R15x60mm
Air consumption (l/min) 540
Blow frequency (1/min) 2550
Bore (mm) 28
Connection thread 13 mm
Length (mm) 410
Piston stroke (mm) 61
Product Name Art. nr. Weight Delivery Time Price Qty
Line lubricator Lubro Star E10/1/1B - 0.6 liter

0.6 liter with feedcap, incl. 2x coupling 1".

709003 2.30 1 Work day £285.54
Lubricator Lubro Star E15/4/1B

4 liter 1" Built-in Lubricator without accessories.

708992 3.50 1 Work day £633.93
Lubricator Lubro Star E21/8/1B

8 liter 1" Built-in Lubricator without accessories.

708995 5.00 1 Work day £709.05
Lubricator Lubro Star SE15/4/1B

4 liter 1" Complete Stand Alone.

708991 6.50 1 Work day £746.46
Lubricator Lubro Star SE21/8/1B

8 liter 1" Complete Stand Alone.

708998 11.00 1 Work day £822.15
Lubricator Lubro Star SE21/9/2B

9 liter 2" Complete Stand Alone.

709006 14.60 1 Work day £865.65
Lubricator Lubro Star EH21/10/2AG

10 liter 2" Built-in Lubricator without accessories.

709010 11.50 1 Work day £1,277.73
Lubricator Lubro Star E21/9/2B

9 liter 2" Built-in Lubricator without accessories.

708993 6.10 1 Work day £769.95
Lubricator Lubro Star E21/9/1.5B

9 liter 1.5" Built-in Lubricator without accessories.

709004 5.60 1 Work day £660.87
Air hose 19 inner dia.

Roll of 20mtr
with couplings

709818 13.00 1 Work day £113.10
Air hose 10 inner dia.

TPE hose - Roll of 50 meter

709811 8.00 1 Work day £152.25
Air hose 19 inner dia.

Roll of 20mtr
without couplings

709819 12.00 1 Work day £72.91
Lightweight Air hose 20 inner dia.

Roll of 20mtr
with hose clamps and claw couplings

709821 4.50 1 Work day £150.51
Lightweight Air hose 20 inner dia.

Roll of 60mtr
without clamps and couplings

709822 12.00 1 Work day £308.85
Air hose 19 inner dia. ¾"

Roll of 25mtr
without couplings

709817 15.00 On request £87.65
Air hose 19 inner dia. ¾"

Roll of 25mtr
with clamps and couplings

709806 16.00 1 Work day £109.40

Choose Tool Breaker

Chipping hammer Rockair GV5D
